Brushed Electric Motor E30-400-48, 24V, 48V, or 72VDC, 5800 rpm

The AmpFlow E30-400-48 motor combines high performance and efficiency with an affordable price tag. Utilizing four brushes and cutting-edge electromagnetic computer modeling and design, this reversible motor is versatile, able to operate with voltages from 24V to 72V (with RPM corresponding to voltage). Running at 48 volts, it achieves a no-load speed of 5800 RPM. This motor boasts a peak short-term power output of 2000 Watts (2.7 horsepower) while maintaining peak efficiency of 82% when drawing 15 Amps at 5300 RPM. Operating at 15 Amps, it delivers 600 Watts (0.80 horsepower). Crafted from two robust aluminum castings and a seamless body, the motor has a diameter of 3.1 inches and a length of 5.8 inches. Its 1/2-inch diameter shaft is two inches long, supported by two high-quality ball bearings. Additionally, there is a 3/8-inch diameter shaft at the rear for mounting an optical encoder. The motor leads are heavy-gauge 12 AWG and are 18 inches long. Weighing 5.9 pounds, the motor is finished with a durable black powder-coat paint. An optional gearhead is available, just search for "AmpFlow Gearmotors". AmpFlow® motors find applications in diverse fields such as robotics, industrial motion control, factory automation, semiconductor manufacturing, power tools, pumps, and personal transport systems. Explore the wide range of AmpFlow motors by searching for "AmpFlow motors". This motor measures 3.1 inches in diameter (78 mm) and 5.8 inches in length (147 mm), with a no-load RPM of 5800 at 48 volts and compatibility with voltages from 24V to 72VDC. It delivers a maximum power of 2000 watts (2.7 horsepower), with a peak efficiency of 82% at 15 amps and 5300 RPM. At peak efficiency, it generates 600 watts (0.80 horsepower) and 1060 mNm (150 oz-in) of torque.

product information:

Attribute	Value
package_dimensions	‎10.83 x 4.49 x 4.45 inches; 5.9 Pounds
item_model_number	‎E30-400-48
date_first_available	‎April 10, 2020
manufacturer	‎Powerhouse Engineering Inc.
country_of_origin	‎China
best_sellers_rank	#501,881 in Tools & Home Improvement (See Top 100 in Tools & Home Improvement) #1,670 in Electric Fan Motors
customer_reviews	ratings_count 13 stars 4.5
